This is Q6 Series
Next Generation Pocket Charger
Double up the power capacity, thinner, lighter
Brand new ISDT Q6 Plus with rounded edge design easily stows in bag or pocket. Same size as the SC-608 charger with twice the power capacity.
2.4″ IPS Display
up to 178° visible angle, auto-brightness screen, still visible under strong sunlight.
Highly optimized internal construction with higher cooling efficiency.
Higher speed and efficiency synchronous Digital Power Supply Technology.High speed ball-bearing fan promotes active cooling increase by 300%, even though the size has been reduced by 50%.
Outstanding performance from every perspective
ARM 32bit high speed Processor
Instant boot (within seconds) when initialized
After the depth of optimizationscOs，Instant Boot, only a few seconds
One key shuttle control
One key metal shuttle control replaces the multi-button press operation, makes charging with the Q6+ a delightful experience.
scOsSpecially designed for smart charging OS
Bright, colorful, easy access set-up and status display. 80% deduction of operation process. Firmware updates can be performed using a personal computer.
3rd Generation Smart Balance Charger
Increased accuracy, with slight charging voltage adjustment capability.
Multiple Languages
Comes in a variety of languages to suit your needs.
产品规格参数
| 1. 2.4”IPS Display |
| 2. Power Input |
| 3. Update Port |
| 4. Opto- sensor |
| 5. Speed Shuttle key |
| 6. Balanced Port |
| 7. Battery Port |
| Q6 Lite | Q6 | Q6 Pro | |
|---|---|---|---|
| Input Voltage | DC 7-32V | DC 7-32V | DC 7-32V |
| Maximum input current | 12A | 15A | 15A |
| Output voltage | 0-30V | 0-30V | 0-30V |
| BattGO™ Support smart battery | not support | not support | Output support |
| Charge Current | 0.1-8.0A | 0.1-14.0A | 0.1-14.0A |
| Discharge Current | 0.1-3.0A | 0.1-3.0A | 0.1-3.0A |
| Max Charge Capacity | 200W | 300W | 300W |
| Max Discharge Capacity | 5W | 8W | 8W |
| Balancing Current | 0.8A/cell | 1.0A/cell | 1.0A/cell |
| Balance Cells | 2-6S | 2-6S | 2-6S |
| Color | gray | black / white | multi-color cover |
| Supported Battery Type | LiFe/Lilon/LiPo/LiHv (1-6S) NiMH/Cd (1-16S) Pb (1-12S) |
LiFe/Lilon/LiPo/LiHv (1-6S) NiMH/Cd (1-16S) Pb (1-12S) |
LiFe/Lilon/LiPo/LiHv (1-6S) NiMH/Cd (1-16S) Pb (1-12S) |
| Display | 2.4〃320×240 IPS LCD | 2.4〃320×240 IPS LCD | 2.4〃320×240 IPS LCD |
| Operating Temperature | 0-40°C | 0-40°C | 0-40°C |
| Storage Temperature | -20-60°C | -20-60°C | -20-60°C |
| Dimensions | 80x80x33.5 mm | 80x80x33.5 mm | 80x80x33.5 mm |
| Weight | 119g | 119g | 119g |
توضیحات اضافی
اطلاعات اضافی
| تولید کننده | iSDT |
|---|
