Description
- 360KV
- 2600RPM
- High strength construction with light weight
- Precise CNC manufacture
The T-Motor Navigator MN3510 360KV Brushless Motor comes with bearing twice as large as the same size motor. Qualified big ball bearings,which suit low speed smooth running and allow for a stable frame against pressure,are put into application precision.
Specifications
- KV: 360
- Configu ration: 12N14P
- Stator Diameter: 35mm
- Stator Length: 10mm
- Shaft Diameter: 4mm
- Motor Dimensions(Dia.*Len): Φ41.8×28.5mm
- Weight (g): 97g
- ldle current(10)@10v(A):0.4A
- No.of Cells(Lipo): 3-6S
- Max Continuous current(A)180S:15A
- Max Continuous Power(W)180S: 330W
- Max. efficiency current: (2-8A)>85%
- internal resistance:188mΩ
