Specifications
KV..............................................................................................................1100
Configu ration...................................................................................12N14P
Stator Diameter....................................................................................22mm
Stator Length...........................................................................................8mm
Shaft Diameter................................................................................3.175mm
Motor Dimensions (Dia.*Len)...........................................Φ27.5×24.5mm
Weight (g)...................................................................................................45g
ldle current(10)@10v(A)..........................................................................0.1A
No.of Cells(Lipo).....................................................................................3-4S
Max Continuous current(A)180S............................................................12A
Max Continuous Power(W)180S........................................................180W
Max. efficiency current.................................................................(2-6A)>80%
internal resistance..............................................................................165mΩ
KV..............................................................................................................1100
Configu ration...................................................................................12N14P
Stator Diameter....................................................................................22mm
Stator Length...........................................................................................8mm
Shaft Diameter................................................................................3.175mm
Motor Dimensions (Dia.*Len)...........................................Φ27.5×24.5mm
Weight (g)...................................................................................................45g
ldle current(10)@10v(A)..........................................................................0.1A
No.of Cells(Lipo).....................................................................................3-4S
Max Continuous current(A)180S............................................................12A
Max Continuous Power(W)180S........................................................180W
Max. efficiency current.................................................................(2-6A)>80%
internal resistance..............................................................................165mΩ
توضیحات اضافی
اطلاعات اضافی
| تولید کننده | T-MOTOR |
|---|
